NDT

NOVO PORTABLE DIGITAL RADIOGRAPHY SYSTEMS
NOVO PORTABLE DIGITAL RADIOGRAPHY SYSTEMSNOVO DR SystemNOVO WITH GOLDEN XRS

NOVO PORTABLE DIGITAL RADIOGRAPHY SYSTEMS

NOVO DR, Israel, is proud to introduce the latest generation of Portable Digital Radiography X-Ray Inspection Systems. Digital Radiography or DR is an advancement of traditional radiography.

Product Description

NOVO DR, Israel, offers NDT professionals Portable Digital Radiography X-Ray Inspection Systems designed for field and laboratory operation, whilst providing the highest image quality.

In contrast to film or Computed Radiography, Digital Radiography (DR) uses an X-ray digital image capturing device (Detector).  This technology enables the operator to generate immediate and high quality X-ray images while keeping radiation levels to a minimum.  Once generated the X-ray image is displayed on a tablet immediately, then using the system’s user friendly proprietary software, the image can be processed, enhanced, shared and digitally stored and accessed on the spot.

Having DR as NOVO’s core technology, they have developed and customized a compact, lightweight, rugged, weather proof system with wireless and battery operation capabilities.  These features allow the operator to examine tight and  elevated places, offer a fast workflow and prolong operation time making the system ideal for the various NDT applications.

Popular Applications:

  • Oil and Gas, Aerospace, Shipyards, Construction, Munitions, Railways, Power Lines.

System Highlights:

  • Cutting Edge Detectors: Thinnest, Lightest, most Durable. 15.6 mm thin, 150 kg Proof Load, Drop Tested 50 cm).High Dose Compatible.
  • Smallest Footprint: Complete System in a 25″ Pelican Case on Wheels.
  • Parallel Multi Location Control and Display: Downrange Wearable Tablet, or Safe-Zone Extra Large Tablet.
  • Highest Image Quality: 16 bit Latest Generation.
  • Most Rugged System: MIL-DTL 38999 Connectors, MIL-STD-810G Tablets.
  • Touch Software: Simple Touch Interface.
  • Longest Battery Life:  Over 16 hours of battery operation.

The system is available in the following models:

NOVO 15 DISCOVERY:

  • NOVO 15WN Detector (9.1″ x 11.2″ Imaging Area).
  • Panasonic Toughpad™ FZ-G1 Tablet (10.1″ Display).
  • NOVO Touch Professional Software.
  • Wired and Wireless Communication.

NOVO 15 DISCOVERY 4K:

  • NOVO 15WN Detector (9.1″ x 11.2″ Imaging Area).
  • Panasonic Toughpad™ 4K Tablet (20″ Display).
  • NOVO Touch Professional Software.
  • Wired and Wireless Communication.

NOVO 22 DISCOVERY:

  • NOVO 22WN Detector (14″ x 16.8″ Imaging Area).
  • Panasonic Toughpad™ FZ-G1 Tablet (10.1″ Display).
  • NOVO Touch Professional Software.
  • Wired and Wireless Communication.

NOVO 22 DISCOVERY 4K:

  • NOVO 22WN Detector (14″ x 16.8″ Imaging Area).
  • Panasonic Toughpad™ 4K Tablet (20″ Display).
  • NOVO Touch Professional Software.
  • Wired and Wireless Communication.

The system is housed in a 25″ Pelican™ Case and includes a Detector,  Tablet and Software, Control Box, 50M Communication Cable on a Reel, Tripod Mount and additional Modules and Cables.  In addition, the Discovery system is designed to hold a variety of Golden X-ray Sources: The XR150, XR200 and XRS3.

For further information please email: ndt@ndt.com.au
